Item Description

TCM Forklift Master Cylinder 239A5-40102 | HACUS | New

New HACUS Aftermarket Replacement Brake Master Cylinder

Replace a worn, leaking, or damaged brake master cylinder with this New HACUS Aftermarket TCM Forklift Master Cylinder , part number 239A5-40102 .

The master cylinder is a critical component of the forklift hydraulic braking system. It converts force from the brake pedal into hydraulic pressure to operate the forklift's brakes.

Part 239A5-40102 is listed for a wide range of TCM forklift applications, including FCG and FG-series models equipped with H20II, H25, K21, and K25 engines.

Part Information

Specification	Details
Brand	HACUS
Condition	New
Part Number	239A5-40102
Alternate Number	TC239A5-40102
Cross Reference	239A5-40101
Part Type	Brake Master Cylinder
Equipment	TCM Forklift
Application	Hydraulic Braking System
Quantity	1 Master Cylinder

The part is also identified under TCM239A5-40102, TC239A540102, and 239A540102 in forklift parts catalogs.

Compatible TCM Forklift Applications

Published application information includes:

TCM FCG Series

• FCG15-2

• FCG15-3

• FCG18-2

• FCG18-3

• FCG20-2

• FCG20-2H

• FCG20-3

• FCG20-3H

• FCG23-2

• FCG23-2H

• FCG23-3

• FCG23-3H

• FCG25-2

• FCG25-2H

• FCG25-3

• FCG25-3H

• FCG28-2

• FCG28-2H

• FCG28-3

• FCG28-3H

• FCG30-2H

• FCG30-3

• FCG30-3H

TCM FG / FHG Applications

Also listed for applications including:

• FG20T6

• FG25T6

• FG20T7

• FG25T7

• FG25C7

• FHG15C2

• FHG15T2

• FHG18T2

• FHG20T7

• FHG25T7

Other catalogs list the 239A5-40102 for additional TCM FD/FG T6, T7, W6, W7, T12, C12, T17 and related configurations.

Engine Applications

Depending on the forklift configuration, applications include:

• Nissan H20II

• Nissan H25

• Nissan K21

• Nissan K25

The exact engine/application combination should be verified using the forklift model and serial number.

Product Features

• New HACUS aftermarket replacement

• Direct replacement-style brake master cylinder

• Designed for TCM forklift braking systems

• Replaces TCM 239A5-40102

• Cross-reference to 239A5-40101

• Helps restore proper hydraulic brake pressure

• Suitable for applicable TCM FCG, FG and FHG forklifts

• Designed for demanding material-handling applications

Brake System Function

The master cylinder is responsible for converting mechanical brake-pedal force into hydraulic pressure.

A failing master cylinder may cause:

• Soft or spongy brake pedal

• Reduced braking performance

• Brake fluid leakage

• Pedal sinking toward the floor

• Difficulty stopping the forklift

• Uneven or inconsistent braking

Replacing a defective master cylinder can help restore proper hydraulic brake operation when the rest of the braking system is in good condition.

Cross-Reference Numbers

This replacement may be identified by:

• TCM 239A5-40102

• TC239A5-40102

• TCM239A5-40102

• 239A540102

• 239A5-40101

Some parts catalogs also reference 239G5-40102 and Komatsu 3BA-36-51141 in connection with this application. Always verify the physical part and equipment application before ordering.

Important Fitment Information

Please verify your forklift model, serial number and original master cylinder part number before ordering.

TCM used different brake configurations across models and production years.

Please compare:

• Original part number

• Forklift model

• Serial number

• Master cylinder mounting configuration

• Hydraulic outlet location

• Port/thread configuration

• Overall dimensions

• Brake system configuration

Do not rely solely on the forklift model for fitment.

If you are unsure, send us your TCM forklift model and serial number before purchasing so the application can be checked.

Installation & Safety

This is a safety-critical brake component .

Installation should be performed by a qualified forklift technician.

After installation:

• Properly bleed the brake hydraulic system.

• Use the correct brake fluid specified for the forklift.

• Check all hydraulic connections for leaks.

• Verify proper brake-pedal operation.

• Confirm the forklift stops safely and evenly.

• Inspect the complete braking system before returning the forklift to service.

Do not operate the forklift if the braking system is not functioning properly.

Package Includes

1 × New HACUS TCM Forklift Brake Master Cylinder

Part Number: 239A5-40102

Cross Reference: 239A5-40101
